Matek F722-PX Flight Controller w/Pixel OSD Dual-Camera Flight Controller FPV ATL
Matek F722-PX Flight Controller w/Pixel OSD Dual-Camera Flight Controller FPV ATL
Matek F722-PX Flight Controller w/Pixel OSD Dual-Camera Flight Controller FPV ATL

F722-PX Flight Controller w/Pixel OSD Dual-Camera

Vendor
Matek
Regular price
$45.99
Sale price
$45.99
Unit price
per
Shipping calculated at checkout.
Product Specs
# of UARTs 6
Processor Type F7
Stack Size 30.5x30.5mm
Camera Control YES
Operating Voltage 9-36V
Part Weight 6.5g


SPECS

  • MCU: 216MHz STM32F722RET6
  • IMU: MPU6000 (SPI)
  • Baro: BMP280 (I2C)
  • OSD: Pixel OSD/FrskyOSD (Uart6)
  • Blackbox: 32M-byte Flash memory (SPI)
  • 6x Uarts with built-in inversion
  • 1x Softserial_Tx option
  • 10x Dshot/PWM outputs
  • 1x I2C
  • 4x ADC (VBAT, Current, RSSI, AirSpeed)
  • 1x SH1.0_8pin connector (Vbat/G/Curr/Rx3/S1/S2/S3/S4)
  • 3x LEDs for FC STATUS (Blue, Red) and 3.3V indicator(Red)
  • Switchable Dual Camera Inputs
  • Switchable 5V/8V for VTX
  • PWM camera control: Yes
  • TR/SA VTX control: Yes
  • WS2812 Led Strip : Yes
  • Beeper : Yes
  • RSSI: Yes
  • Analog Airspeed sensor: Yes
  • Digital Airspeed sensor: Yes

Power

  • Input: 9~36V (3~8S LiPo)
  • BEC: 5V 2A cont. (Max.3A)
  • BEC: 8V 2A cont. (Max.3A)
  • LDO 3.3V: Max.200mA
  • Battery Voltage Sensor: 1:10 (Scale 110)
  • No Current Sensor built-in

FC Firmware

  • BetaFlight unified target: MATEKF722PX(MTKS)
  • INAV target: MATEKF722PX

Physical

  • Mounting: 30.5 x 30.5mm, Φ4mm with Grommets Φ3mm
  • Dimensions: 36 x 36 x 5 mm
  • Weight: 6.5g

Including

  • 1x FC F722-PX
  • 6x Silicon grommets M4 to M3
  • 1x SH1.0_8pin cable 5cm
  • 2x SH1.0_8pin connectors
